LDT-PS70 Pocket Spring Machine - Ladetech Mattress Machine

Capacity

70pcs/min

Wire Diameter

1.6-2.2mm

Pocket Spring Height

80-200mm

Spring Waist Diameter

55-72mm

Contact Us Send Inquiry

Product Description

LDT-PS70 pocket spring machine is used to produce back-sealed pocket springs for mattresses. It can automatically complete the winding, heat treatment, conveying and pocket forming of springs in a complete cycle. Our pocket spring machine has advantages of high performance, high efficiency, high stability and easy operation and maintenance.

Technical Characteristics

1.High efficient performance, high stability, low failure rate, low scrap rate.

2.Mechanical conveying is controlled by servo system.

3.Ultrasonic sealing.

4.Movable heat treatment mechanism for springs of different heights.



Technical Specifications

Capacity

70pcs/min

Coiling Head

Cam Coiling head

Pocket Spring Shape

Barrel and Cylindrical

Wire Diameter

1.6-2.2mm

Pocket Spring Height

80-200mm

Spring Waist Diameter

55-72mm

Air Consumption

0.5m³/min

Air Pressure

0.6-0.7Mpa

Voltage

3 Phase, 380V, 50/60HZ

Weight

2000 KG
